s quick coupler
LINGDONG S Quick Coupler follow the S-standardsystem. It features a cast structure, hydraulicactuation, and is equipped with a rear pin safetylocking mechanism. All solutions comply withinternational safety standards such as EN 474 and Is0 13031.
Product Description
S-standard quick coupler
For 4-20 ton excavators
LINGDONG S Quick Coupler follow the S-standardsystem. It features a cast structure, hydraulicactuation, and is equipped with a rear pin safetylocking mechanism. All solutions comply withinternational safety standards such as EN 474 and Is0 13031.
| Quick coupler | S40 | S45 | S50 | S60 |
|---|---|---|---|---|
| Pin diameter (A) | 40 | 45 | 50 | 60 |
| Width (B) | 200 | 290 | 270 | 340 |
| Pin distance (C) | 300 | 430 | 430 | 480 |
| Pin height (D) | 48 | 62 | 63 | 79 |
| Pin distance (E) | 115 | 130 | 135 | 160 |
| Pin diameter (F) | 35-45 | 45-50 | 45-50 | 60-65 |
| Max width dipper arm (G) | 120-150 | 180-220 | 180-220 | 220-260 |
| Min Pin distance (H) | 160 | 220 | 220 | 350 |
| Max Pin distance (I) | 270 | 365 | 365 | 410 |
| Length (J) | 425 | 588 | 587 | 482 |
| Pin Width (K) | 250 | 369 | 359 | 472 |
| Height (L) | 228 | 274 | 280 | 344 |
