Crushing tongs shear
Suitable for excavators weighing 3-35 tons
Imported blades have long working life, and the wear-resistant plates are stable and durable
Greater crushing force, 360-degree rotation function can be customized
Can be customized according to needs
Product Description
Crushing tongs
Suitable for excavators weighing 4-40 tons
The main body uses manganese plate wear-resistant plate, which has strong crushing force and is easy and quick to replace teeth
360-degree rotation function can be customized on demand
Special customization can be made according to needs
All introductions and configurations are basic models. Lingdong Company has the right to change parameters and the final right of interpretation
Parameter table:
Model Model HCP02 HCP04 HCP06 HCP08 HCP10
Weight
Weight 310kg 510kg 1000kg 1700kg 2700kg
Crushing force
Crushing force 170/260 kn 350/560 kn 520/840 kn 700/1170 kn 1000/1600 kn
Maximum opening
Maximum opening 420mm 600mm 750mm 860mm 1100mm
Working flow
Working flow 80-120L/min 100-140L/min 120-180L/min 180-250L/min 200-300L/min
Blade length
Blade length 75mm 95mm 112mm 180mm 360mm
Compatible Excavator
Compatible Excavator 4-6 ton 6-9 ton 10-15 ton 15-25 ton 30-40 ton
